ZeroPuck
The Industries first Internal intelligent Side Mount socket system with Constant Vacuum socket technology. The ZeroPuck SP system is cutting edge prosthetic socket technology that can actually improve the circulation and health of the residual limb.
FEATURES
-
Smart Constant Vacuum -Set and Forget
-
APPLE / ANDROID Smart Device Compatible
-
Integrated Valve
-
Easy ON/OFF Magnetic Hall Switch
-
Negative Pressure Tank for Extended Vacuum life
-
External Charger
-
Advanced Vacuum Technology
-
Self Sealing Design
-
Light weight and Low Build Height
Now Waterproof
Tested to IP28 (3 meters of water for up to 4 hours).
All new ZeroPucks sold after August 1st, 2025 will be IP28 waterproof. Look for the IP28 designation engraved on the base of the ZeroPuck. All ZeroPucks without the IP28 designation are not waterproof. ZeroPucks sold before August 1st, or without the IP28 designation, can be sent in for refurbishment, updating them to the new IP28 standard.
SPECIFICATION
-
Height: 3.69” / 94mm
-
Width: 2.17”/ 55mm
-
Depth: 1.47” / 38mm
-
Weight: 109 g
-
Weight Limit: Unlimited
-
Fabrication: Drop In
-
Max Vacuum: 24 In//Hg
-
Seal: Self Sealing
-
Battery Life: 2-3 Days
-
PATENT: US9119735 B2, Additional Patents Pending
LINER COMPATIBILITY
-
All Naked Silicone and Urethane liners
-
Otto Bock™ Urethane, Ossur™, Evolution™ & ESP™
-
GEL or TPE Liners are not Recommended
-
Sealing Liners: The seal of the liner must sit ABOVE the ZeroPuck inside the socket to properly seal the socket.
SLEEVE / SEALING LINER COMPATIBILITY
-
SEALING LINERS (Liner w/ integrated seal)
-
Ossur™ Aura™ Sock, Echo™ Sock
-
ESP™ Seal Ring™
-
SEALING SLEEVE
-
Use Silicone, TPE or Urethane Sealing Sleeves
-
Sleeves Should be a good fit and Sticky Inner surface
-
NO integrated Fabric on sleeve interior
A description of Coyote's ZeroPuck
Elevated Vacuum System
